Description

In this version the drying section consists of a vertical compartment across which rows of air channels are installed. One end of each channel is open and the other closed.

Alternative rows are open to the plenum chamber and intervening rows to the exhaust section. Alternate rows are also offset so that channel tops divide the moving stream of grain as it descends, providing considerable mixing and uniform drying.

Technical Specifications

Key Features

• Vertical compartment design Tower Type
• Offset air channel rows for grain mixing
• Plenum chamber for even hot air distribution
• Separate exhaust section per row
• Gravity descent of grain — continuous operation
• High drying capacity — 8000 Ltrs
• Compact footprint — 2.46 × 2.46 m base
